The core components of the sewage mixer mainly include the following parts:

First, impeller

Function: The impeller is the core mixing component of the sewage mixer, and the sewage and the sludge in it are stirred evenly by rotating motion.

Form: According to different working environment and mixing needs, there are many forms of impeller, such as word blade, three-word blade, six-word blade and so on. The mixing effect of sludge can be optimized by selecting different types of impellers.

Second, transmission device

Composition: Transmission device includes motor, reducer, transmission shaft and other components.

Function: The motor provides power, reduces the speed and increases the torque through the reducer, and then passes to the drive shaft to make the impeller rotate and stir.

Features: The vertical sewage treatment mixer usually adopts cycloidal pin gear reducer, and the working part of the main machine adopts nylon pin as the transmission connector to achieve teeth and transmission drive, which is easy to assemble and maintain.

Third, the frame

Function: The frame is the supporting structure of the sewage mixer, and all the working bodies are installed and fixed on the frame.

Materials: The frame is usually welded with high-strength materials such as superior carbon steel plate and channel steel to ensure the stability and durability of the equipment.

Fourth, sealing mechanism

Function: For submersible sewage mixer, the sealing mechanism is a key component to prevent water and sewage from entering the motor interior.

Importance: Good sealing performance can ensure the safe operation of the motor and prevent short circuit or damage caused by water intrusion.

Fifth, electrical control part

Function: The electrical control part is responsible for controlling the start, stop and speed regulation of the motor.

Composition: including control panel, switch, governor and other components.

Safety: The electrical control part usually has overload protection, short circuit protection and other safety functions to ensure the stable operation of the equipment and personnel safety.

In summary, the core components of the sewage mixer include impeller, transmission device, frame, sealing mechanism and electrical control part. These components work together to achieve efficient mixing and treatment of wastewater. When maintaining and maintaining the sewage mixer, attention should be paid to the status and performance of these core components to ensure the long-term stable operation of the equipment.
