Sewage mixers may encounter a variety of common faults during operation, which usually involve mechanical, electrical and operational aspects. Here are some common failures and their possible causes:

First, mechanical failure

Vibrate or sway

Reasons: Inundation depth is not enough, forming whirlpools and inhaling air; The pool capacity is small, the mixing is too violent, resulting in the impeller unbalance; Guide rod support installation foundation loose; Multiple devices interfere with each other; The impeller is damaged.

Solution: increase the submerged depth; Select the equipment suitable for the pool volume; Re-reinforce the guide rod support; Increase equipment spacing or set anti-interference board; Replace the damaged impeller.

Excessive load current

Reason: strong viscosity or high concentration of liquid; Rotation direction is wrong; Impeller obstruction; The guide hood interferes with the impeller.

Solution: Use high-power equipment; Change the rotation direction; Remove debris on the impeller; Adjust the clearance between impeller and fairing.

Abnormal noise

Reason: the guide hood and impeller interference; The bearing is damaged.

Solution: Adjust the gap between the impeller and the fairing; Replace damaged bearings.

Seal failure

Cause: Mechanical seal wear, resulting in the sealing cavity water.

Solution: Check and replace the worn mechanical seal parts to ensure the sealing performance of the sealing chamber.

Second, electrical failure

Motor does not respond or does not start

Cause: The power line contact is poor; The motor is damp or water; There is debris blocked inside the motor; The fuse is blown.

Solution: Check the power line and reconnect; Ensure that the motor is dry and free of debris; Replace the blown fuse.

Stator overtemperature alarm

Cause: the load current is too large; Electronic overtemperature alarm device is damaged; The motor is damaged.

Solution: Check the load and reduce the load appropriately; Replace the damaged electronic overtemperature alarm device; Check motor performance and repair or replace it if necessary.

Third, operation failure

Poor mixing effect

Cause: improper mixing speed setting; There are dead corners in the mixing tank; The mixing medium is not uniform.

Solution: Adjust the mixing speed to the appropriate range; Optimize the mixing tank design to eliminate dead corners; Make sure the mixing medium is evenly mixed.

Equipment clogging

Reason: the stirring medium contains a large number of solid particles or fiber materials; Agitator design is not reasonable, easy to accumulate debris.

Solution: Clean the mixer and its surrounding area regularly to prevent the accumulation of debris; Optimize blender design to reduce clogging risk.

Fourth, other faults

Oil chamber leak alarm

Solution: Change the oil and check it again after 3 weeks. If the current situation persists, check the mechanical seal section.

Bearing overheating

Reasons: insufficient lubrication or lubricating oil deterioration; Bearings are improperly installed or damaged.

Solution: check and replenish or replace the lubricating oil; Reinstall or replace damaged bearings.

To sum up, the common faults that may be encountered in the operation of the sewage mixer involve many aspects such as mechanical, electrical and operational. To ensure the normal operation and prolong the service life of the device, check and maintain the device regularly to discover and handle faults in time. At the same time, operators should be familiar with the operation procedures and precautions of the equipment to avoid faults caused by misoperations.

Nanjing LanJiang Water Treatment Equipment Co.,Ltd manufactures equipment for wastewater treatment. We were established in 2001. Since then, we designed and produced submersible mixers, top entry mixers, aerators and other wastewater treatment equipment.
